Date Code OCR Inspection System
Checks every date and lot code for presence and correctness.
Built around your product
A smart camera with strobed lighting reads printed or lasered date codes and compares them with the expected text. Missing, wrong or unreadable codes are rejected and counted.
A triggered camera with matched lighting captures each product. Software tools locate the code, read characters (OCR), compare them with the expected string (OCV), decode 1D and 2D symbols and measure print quality. Results drive a reject device and are logged for audit. Fixed-mount verifiers grade codes to ISO/IEC 15415 and 15416.
Key features
- Learns inkjet dot-matrix fonts
- Auto-updates expected data from the coder
- Reject statistics on the HMI
- Compact bracket for conveyor mounting
Process sequence
Trigger
A sensor fires the camera as each product reaches the field of view.
Illuminate
Strobed LED lighting freezes motion and controls reflections.
Analyse
Algorithms read, match and grade codes and check label position.
Decide
Pass or fail is issued within milliseconds.
Reject
An air blast or pusher removes failed products and confirms the reject.
Machine video
A closer look at a typical vision & code inspection installation. Ask us for a live demonstration of the VS-OCR1 on your own product.
Specifications
| Model | VS-OCR1 |
|---|---|
| Inspection | OCR / OCV, code presence |
| Camera | 1.6 MP monochrome smart camera |
| Code types | Dot-matrix and solid fonts, 1D / 2D |
| Max speed | Up to 600 products/min |
| Lighting | Integrated white or red LED ring |
| Reject | Air-blast output |
| Interfaces | Ethernet, I/O, printer handshake |
| Protection rating | IP65 camera |
Typical configuration. Final values depend on your product and are confirmed in the quotation.
Add-ons
- Air-blast, pusher or diverter reject
- Reject-confirmation and bin-full sensors
- Audit trail and user management
- Multi-camera 360° inspection
Suitable materials and packs
Questions
What is the difference between reading and verifying?
Can it check inkjet date codes?
Does it connect to the printer?
