Inline Spindle Capping Machine
Tightens screw caps continuously without stopping the bottle.
Built around your product
Caps are sorted, delivered down a chute and picked up by the moving bottle. Sets of spinning discs tighten each cap to an adjustable torque while gripper belts hold the container.
The filling principle follows the product. Piston fillers meter viscous products by cylinder volume. Gravity and overflow fillers suit thin, foaming liquids and give a consistent cosmetic fill level. Auger fillers dose powders by screw rotation. Cappers then place and tighten screw, press-on or pump closures to a set torque.
Key features
- Handles screw, sport and trigger caps
- Adjustable clutch torque
- Elevator or vibratory cap sorter
- Fast changeover with digital position readouts
Process sequence
Feed
Containers are unscrambled and spaced on the conveyor.
Index
Gates or a starwheel position containers under the nozzles.
Fill
Nozzles dive, dose and retract with anti-drip cut-off.
Cap
Closures are sorted, placed and torqued.
Code
A laser or inkjet coder marks date and lot before labelling.
Machine video
A closer look at a typical filling & capping installation. Ask us for a live demonstration of the FC-C1 on your own product.
Specifications
| Model | FC-C1 |
|---|---|
| Filling principle | Spindle capper, continuous motion |
| Fill range | Cap Ø 18–70 mm |
| Heads | 4 pairs of spindle wheels |
| Output | Up to 150 bottles/min |
| Accuracy | Torque repeatability ±10% |
| Container range | Ø 20–150 mm, up to 320 mm tall |
| Contact parts | 304 stainless steel frame |
| Power / air | 220 V, 1.2 kW / 6 bar |
Typical configuration. Final values depend on your product and are confirmed in the quotation.
Add-ons
- CIP-ready product path
- Diving and bottom-up fill nozzles
- Cap elevator and sorter
- Nitrogen flush before capping
Suitable materials and packs
Questions
Which filler suits viscous products?
How is fill accuracy expressed?
Can filling and capping be combined?
Get a proposal for this machine
- Application review by an engineer — material, code and line speed
- Trial marking, printing or packing on your own samples
- Quotation with layout, lead time, installation and service
Prefer to talk? Email info@motionworksrobotics.com or call +91 98100 93680.
